facebook::yoga::LayoutResults结构体 参考

#include <LayoutResults.h>

facebook::yoga::LayoutResults 的协作图:

Public 成员函数
Direction	direction () const
void	setDirection (Direction direction)
bool	hadOverflow () const
void	setHadOverflow (bool hadOverflow)
float	dimension (Dimension axis) const
void	setDimension (Dimension axis, float dimension)
float	measuredDimension (Dimension axis) const
float	rawDimension (Dimension axis) const
void	setMeasuredDimension (Dimension axis, float dimension)
void	setRawDimension (Dimension axis, float dimension)
float	position (PhysicalEdge physicalEdge) const
void	setPosition (PhysicalEdge physicalEdge, float dimension)
float	margin (PhysicalEdge physicalEdge) const
void	setMargin (PhysicalEdge physicalEdge, float dimension)
float	border (PhysicalEdge physicalEdge) const
void	setBorder (PhysicalEdge physicalEdge, float dimension)
float	padding (PhysicalEdge physicalEdge) const
void	setPadding (PhysicalEdge physicalEdge, float dimension)
bool	operator== (LayoutResults layout) const

Public 属性
uint32_t	computedFlexBasisGeneration = 0
FloatOptional	computedFlexBasis = {}
uint32_t	generationCount = 0
uint32_t	configVersion = 0
Direction	lastOwnerDirection = Direction::Inherit
uint32_t	nextCachedMeasurementsIndex = 0
std::array< CachedMeasurement, MaxCachedMeasurements >	cachedMeasurements = {}
CachedMeasurement	cachedLayout {}

静态 Public 属性
static constexpr int32_t	MaxCachedMeasurements = 8

Private 属性
Direction	direction_: bitCount<Direction>() = Direction::Inherit
bool	hadOverflow_: 1 = false
std::array< float, 2 >	dimensions_ = {{YGUndefined, YGUndefined}}
std::array< float, 2 >	measuredDimensions_ = {{YGUndefined, YGUndefined}}
std::array< float, 2 >	rawDimensions_ = {{YGUndefined, YGUndefined}}
std::array< float, 4 >	position_ = {}
std::array< float, 4 >	margin_ = {}
std::array< float, 4 >	border_ = {}
std::array< float, 4 >	padding_ = {}

成员函数说明

border()

float facebook::yoga::LayoutResults::border ( PhysicalEdge physicalEdge ) const

inline

函数调用图:

dimension()

float facebook::yoga::LayoutResults::dimension ( Dimension axis ) const

inline

函数调用图:

这是这个函数的调用关系图:

direction()

Direction facebook::yoga::LayoutResults::direction ( ) const

inline

这是这个函数的调用关系图:

hadOverflow()

bool facebook::yoga::LayoutResults::hadOverflow ( ) const

inline

这是这个函数的调用关系图:

margin()

float facebook::yoga::LayoutResults::margin ( PhysicalEdge physicalEdge ) const

inline

函数调用图:

measuredDimension()

float facebook::yoga::LayoutResults::measuredDimension ( Dimension axis ) const

inline

函数调用图:

这是这个函数的调用关系图:

operator==()

bool facebook::yoga::LayoutResults::operator==

(

LayoutResults

layout

)

const

函数调用图:

padding()

float facebook::yoga::LayoutResults::padding ( PhysicalEdge physicalEdge ) const

inline

函数调用图:

position()

float facebook::yoga::LayoutResults::position ( PhysicalEdge physicalEdge ) const

inline

函数调用图:

这是这个函数的调用关系图:

rawDimension()

float facebook::yoga::LayoutResults::rawDimension ( Dimension axis ) const

inline

函数调用图:

setBorder()

void facebook::yoga::LayoutResults::setBorder ( PhysicalEdge physicalEdge, float dimension )

inline

函数调用图:

setDimension()

void facebook::yoga::LayoutResults::setDimension ( Dimension axis, float dimension )

inline

函数调用图:

setDirection()

void facebook::yoga::LayoutResults::setDirection ( Direction direction )

inline

函数调用图:

setHadOverflow()

void facebook::yoga::LayoutResults::setHadOverflow ( bool hadOverflow )

inline

函数调用图:

setMargin()

void facebook::yoga::LayoutResults::setMargin ( PhysicalEdge physicalEdge, float dimension )

inline

函数调用图:

setMeasuredDimension()

void facebook::yoga::LayoutResults::setMeasuredDimension ( Dimension axis, float dimension )

inline

函数调用图:

这是这个函数的调用关系图:

setPadding()

void facebook::yoga::LayoutResults::setPadding ( PhysicalEdge physicalEdge, float dimension )

inline

函数调用图:

setPosition()

void facebook::yoga::LayoutResults::setPosition ( PhysicalEdge physicalEdge, float dimension )

inline

函数调用图:

setRawDimension()

void facebook::yoga::LayoutResults::setRawDimension ( Dimension axis, float dimension )

inline

函数调用图:

类成员变量说明

border_

std::array<float, 4> facebook::yoga::LayoutResults::border_ = {}

private

cachedLayout

CachedMeasurement facebook::yoga::LayoutResults::cachedLayout {}

cachedMeasurements

std::array<CachedMeasurement, MaxCachedMeasurements> facebook::yoga::LayoutResults::cachedMeasurements = {}

computedFlexBasis

FloatOptional facebook::yoga::LayoutResults::computedFlexBasis = {}

computedFlexBasisGeneration

uint32_t facebook::yoga::LayoutResults::computedFlexBasisGeneration = 0

configVersion

uint32_t facebook::yoga::LayoutResults::configVersion = 0

dimensions_

std::array<float, 2> facebook::yoga::LayoutResults::dimensions_ = {{YGUndefined, YGUndefined}}

private

direction_

Direction facebook::yoga::LayoutResults::direction_

private

generationCount

uint32_t facebook::yoga::LayoutResults::generationCount = 0

hadOverflow_

bool facebook::yoga::LayoutResults::hadOverflow_

private

lastOwnerDirection

Direction facebook::yoga::LayoutResults::lastOwnerDirection = Direction::Inherit

margin_

std::array<float, 4> facebook::yoga::LayoutResults::margin_ = {}

private

MaxCachedMeasurements

constexpr int32_t facebook::yoga::LayoutResults::MaxCachedMeasurements = 8

staticconstexpr

measuredDimensions_

std::array<float, 2> facebook::yoga::LayoutResults::measuredDimensions_ = {{YGUndefined, YGUndefined}}

private

nextCachedMeasurementsIndex

uint32_t facebook::yoga::LayoutResults::nextCachedMeasurementsIndex = 0

padding_

std::array<float, 4> facebook::yoga::LayoutResults::padding_ = {}

private

position_

std::array<float, 4> facebook::yoga::LayoutResults::position_ = {}

private

rawDimensions_

std::array<float, 2> facebook::yoga::LayoutResults::rawDimensions_ = {{YGUndefined, YGUndefined}}

private

---

该结构体的文档由以下文件生成:

• third/yoga/yoga/node/LayoutResults.h
• third/yoga/yoga/node/LayoutResults.cpp
